Core Turnover Table Suit for Stacking and Tilting for 3 Limbs and 5 Limbs

Basic Info

Model NO.	customized
HS Code	8428909090
Production Capacity	30/Month

Product Description

Core Turnover Table suit for stacking and tilting for 3 limbs and 5 limbs

1.Summary

This equipment is mainly used in 200-1250 kva core transformer core stacking

2.Main Technical parameters and requires

Apply Core stacking range
Minimum iron core	861 * 403 * 710 mm
Largest iron core	954 * 253 * 865 mm
Max weight of core	1300 kg
Main stacking table parameters
Platform size	1000 * 760 mm
Slide working length	900mm (fixed)
Adjustable length	two ends the 0-130 mm
Min.H	270mm

3.Basic structure

1)stacking table is consist of base, slide rail , linear and kinds of support etc.

The overall floor were fixed with three slide rail, a fixed rail on the slippery course arrangement and two sliding rail, on both sides of two sliding rail is adjustable.

2)On the both ends of fixed rail and slippery course has total six telescopic long strips, decorate in the fixed railand the top of the slide rail have piled up the fixed bracket (a total of 12 pieces) and the adjustable support (total 6 PCS), and other basic components.

3)Fixed bracket and the bottom of the adjustable support configuration magnetic structure, facilitate random orientation, and make sure the platform not fall of when working.Sliding rail flexible, equipped with a locking mechanism, in place can be carried out after the positioning lock, to prevent accidental sli.

L
we are the factory that designs and produces the production of transformer manufacturing equipment and insulation processing equipment in China.
